SC (B) 14 Dry-Type Distribution Transformer
The dry-type transformer meets high-level energy efficiency standards. As a resin-insulated dry-type transformer, the coil is encapsulated by epoxy resin, making it flame retardant, fireproof, explosion-proof, and maintenance-free. Its non-polluting and compact design allows it to be placed directly in the load center.
Due to scientific design and casting processes, the product features low partial discharge, minimal noise, and strong heat dissipation. It can operate for extended periods under 125% of the rated load with forced air-cooling. Equipped with a temperature controller, it provides fault alarms, over-temperature protection, and centralized monitoring via RS485 interface.
| Rated Capacity (kVA) | Voltage Combination | Vector Group | No-load Loss (W) | Load Loss (120℃) (W) | Short-Circuit Impedance (%) | ||
| HV (kV) | Tap Range (%) | LV (V) | |||||
| 100 | 6 / 10 / 11 | ±5 or ±2×2.5 | 400 | Yyn0 or Dyn11 | 270 | 1415 | 4 |
| 160 | 365 | 1915 | 4 | ||||
| 250 | 490 | 2485 | 4 | ||||
| 400 | 665 | 3590 | 4 | ||||
| 630 | 910 | 5290 | 4 | ||||
| 1000 | 10 / 11 | ±5 | 400 | Dyn11 | 1205 | 7315 | 6.0~8.0 |
| 2000 | 10 / 11 | ±5 | 400 | Dyn11 | 2075 | 13005 | 6.0~8.0 |
Our facility strictly implements ISO9001 Quality Management, ISO14001 Environmental Management, and ISO45001 Occupational Health systems. Leveraging leading production technology and advanced manufacturing equipment, we ensure high standards and consistent product quality across all transformer series.
