HYBO Energy
HYBO Energy
High voltage energy storage systems designed for industrial and commercial applications, providing robust solutions for energy storage needs. Sophisticated 3+1 level BMS architecture offering comprehensive protection and management.
With an integrated flexible networking mode, this advanced system supports both single cluster independent use and multiple cluster parallel applications. Seamlessly online monitor your system's total voltage, current, insulation resistance, and relay bonding. Benefit from real-time cell safety monitoring, intelligent balancing, fault diagnosis, multi-level alarms, and protection.
| Feature | Specification |
|---|---|
| Operation Voltage | DC12V-36V |
| Operation Current | ≤ 35mA(12V)/≤ 20mA(24V) |
| Voltage acquisition strings | 16S~22S, 23S~44S, 45S~66S |
| Voltage acquisition accuracy | ±4msV |
| Temperature acquisition accuracy | ±1ºC |
| Balance | Supports Passive Balance (100mA) |
| Withstand voltage | AC 3100V |
| Size | 170*100*31.2mm / 360*120*31.2mm |
| Product Parameters | BCU | BAU |
|---|---|---|
| Operation Voltage | DC12V-36V | DC12V~36V |
| Operation Current | ≤ 70mA(24V) | ≤ 70mA(24V) |
| Communication (CAN/RS485) | CAN:3 / RS485:2 | CAN:3 / RS485:5 |
| Ethernet Port | 1 | 3 |
| Insulation Detection | Support Input | Support |
| Size | 245*115*29.7mm | 245*106.5*29.7mm |
| Module | Rating / Model | Key Features |
|---|---|---|
| HV Box | DC1000V - 1500V | Rated Current 150A-400A; IP43 Level |
| HMI Display | DMG-A5WTC (7.0") | Capacitive Touch, 1024*600, IP65 Front |
Founded in 2011, our company is a pioneering high-tech enterprise at the forefront of innovation. Our specialty lies in the meticulous research, cutting-edge development, and strategic sales of advanced lithium battery management systems (BMS). We champion refined and innovative technologies, dedicated to delivering unmatched safety, intelligence, and efficiency in lithium battery management solutions worldwide.
Boasting an elite R&D team with over 50 national patents, we lead the charge in digital and platform-based lithium battery safety management. Our robust cloud platform adeptly manages millions of battery packs, offering unparalleled health monitoring and intelligent management services.
