HYBO Energy
HYBO Energy
| Model | Optional |
|---|---|
| Rechargeable | Chargeable |
| Discharge Rate | Medium Discharge Rate |
| Size | Large |
| Battery Type | LiFePO4 Lithium Ion Battery |
| Capacity | 215kwh / 305kwh / 362kwh |
| Standard Voltage | 250V-750V DC |
| Communication | CAN / RS-485 / RS-232 |
| Cycle Life | 6000 Cycles @ 80% DoD |
| Usage | Solar Energy Storage System |
| Certification | CE / UN38.3 / MSDS |
We deliver fully-integrated solar-storage-charging solutions that seamlessly blend rooftop or ground-mounted PV, high-density battery storage, and ultra-fast EV chargers into a single, intelligent ecosystem. During daylight hours, premium bifacial solar modules harvest sunlight and route clean power to charge vehicles; surplus energy is captured in modular, liquid-cooled LFP battery racks. At night or during grid outages, stored energy is dispatched on demand—eliminating peak charges and ensuring constant readiness.
| Parameter | 215KWh+100KW/IP54 | 305KWh+100KW | 362KWh+100KW |
|---|---|---|---|
| Battery Energy | 215KWh | 305KWh | 362KWh |
| PCS Power | 100KW | 100KW | 100KW |
| MPPT Power | 120KW | 120KW | 120KW |
| MPPT Range | 250~850Vdc | 250~850Vdc | 250~850Vdc |
| AC Voltage | 400V/230V | 400V/230V | 400V/230V |
| Protection Level | IP54 | IP54 | IP54 |
| Weight | ~2500kg | ~2930kg | ~3230kg |
| Size (mm) | 1580*1050*2090 | 1580*1190*2355 | 1580*1190*2355 |
Connects the PV system, energy storage system, and charging facilities to a common AC bus through their respective inverters, enabling energy exchange among all devices.
Connects the PV system, energy storage system, and DC charging equipment directly to a high-voltage DC bus. This reduces multiple DC/AC conversions and significantly improves overall system efficiency.
Allows the system to be selectively connected to respective AC or DC buses, providing dynamic energy routing based on real-time demand.
Established in 2011, the manufacturer specializes in the R&D, production, sales, and service of lithium battery packs. Focusing on one-stop customized lithium products including electric vehicle batteries, electric boat batteries, and large-scale energy storage systems. With a dedicated R&D team of 30+ senior engineers, the company utilizes first-grade lithium cells with high energy density. Following strict quality control systems like ISO 9001 and IATF 16949, every system is rigorously tested before delivery.
